How to adjust the pressure parameters of the Briquetting machine

Understanding the Machine's Pressure System

• Familiarize with the Components: First, understand the structure of the briquetting machine's pressure system. It usually consists of a hydraulic pump, pressure gauge, relief valve, and cylinder. The hydraulic pump supplies oil to the cylinder to generate pressure, and the pressure gauge shows the real - time pressure value. The relief valve is used to set the maximum pressure to prevent the system from over - pressurizing.
• Know the Pressure Range: Refer to the machine's manual to know the recommended pressure range for different materials and briquette sizes. This range is based on the machine's design and the characteristics of common raw materials, which provides a reference for initial adjustments.

Adjusting the Pressure Parameters

• Coarse - Tuning: Start with a rough adjustment. If the briquettes are too loose, increase the pressure gradually. Loosen the adjustment screw of the relief valve to allow more oil to flow into the cylinder, thereby increasing the pressure. Observe the pressure gauge and increase the pressure in small increments until the briquettes begin to take shape more firmly.
• Fine - Tuning: After coarse - tuning, perform fine - tuning according to the actual situation. If the surface of the briquettes has cracks or is over - compacted, slightly decrease the pressure. Tighten the adjustment screw of the relief valve to reduce the oil supply and lower the pressure. Continuously monitor the quality of the briquettes and make small adjustments to achieve the best pressure parameter.
• Material - Specific Adjustments: Different materials have different requirements for pressure. For example, materials with high hardness and low plasticity may require higher pressure, while soft and sticky materials may need lower pressure. Adjust the pressure parameters according to the characteristics of the specific material being processed.

During the adjustment process, it is necessary to test and adjust repeatedly to find the most suitable pressure parameters, so as to ensure the quality of the briquettes and the normal operation of the machine.
